科研情况简介

【主要学术特点】

长期以来以提升土建工程质量安全和管理效率为主要目标,集成BIM、物联网、人工智能等技术,结合我国重大工程建设,面向住宅建筑、大型公建、道路桥梁、轨道交通等目标对象,开展了土木工程信息技术有关科学问题和工程方法的研究。

基础科学研究方面,注重土木工程传统学科与现代信息技术的交叉融合,依托国家自然科学基金项目、国家863项目等纵向科研课题,针对当前建筑信息共享和应用中存在的问题,对信息获取、管理、集成、共享和应用进行了基础性研究,提出了包括多尺度建筑信息模型、IFC图像信息模型和施工安全信息模型在内的一系列信息模型并定义其表述方式。在此基础上,研究了多种模型之间的转换和信息共享机制,以及在役结构的安全检测、分析和评估手段,提出了“基于BIM的施工过程结构安全分析和综合管理方法”以及“针对既有建筑物的运维期信息化管理和数字防灾方法”,截止2017年6月,获得发明专利 1 项,发表学术论文50余篇(其中SCI收录9篇,EI收录14篇),累计被引450余次(含SCI他引81次)。

研发自主产权平台方面,通过研究轻量化模型技术、多层次高效三维图形渲染技术,开发了具有自主知识产权的图形平台;通过研究开放平台架构和二次开发支撑技术,开发了插件式开放平台。在此基础上,研发了一系列应用软件系统,获软件著作权十余项(其中评价为国内首创1项、国际领先1项),并形成了一个“大数据云平台+客户/网页/移动三端系统”的体系架构,服务于包括城市轨道交通、高铁、高速公路、隧道、桥梁、大型综合体等多个领域的数十项工程。

促进行业技术进步方面,着力将上述研究成果,结合国家和省市的重大工程及企业的现实需求,以“系统应用”为核心,参与到国家体育场“鸟巢”、青岛海湾大桥、广州西塔、昆明新机场航站楼、上海国际金融中心、深圳机场T3航站楼、深圳嘉里中心II期、北京英特宜家、广州地铁等多个投资几十亿、上百亿的大型建设项目中,重点解决施工过程时变结构安全分析和综合管理,以及运维过程的信息化应用中存在困难的问题。相关成果被纳入国家标准、地方规程和住建部颁发的政策文件。此外,作为中国图学学会BIM专业委员会的秘书长,近3年来一直深度参与BIM技术的科研教育和推广应用工作,作为编委编著《中国建筑施工行业信息化发展报告:BIM应用与发展》、《全国BIM技能等级考评大纲》,作为大会秘书长组织了第一、第二届全国BIM学术会议。

获得华夏建设科学技术奖一等奖等奖励多次,并通过知识产权成果转化,实现产值逾一千万元。



【主要学术创新点】

研究了多种模型之间的转换和信息共享机制,提出了基于BIM的施工过程结构安全分析和综合管理方法,研制了相应的软件系统

通过深入研究BIM的信息表达、数据标准、转换算法、共享机制等,突破了建筑模型、结构模型、结构分析模型之间,以及设计模型、施工模型和运维模型之间的转换和信息共享机制技术,在此基础上,提出了基于BIM的施工过程时变结构安全分析方法,探索了BIM技术在大型工程施工中的落地应用模式与方法,研发了相应的施工过程安全分析系统和施工管理系统4套,实现了施工过程时变结构和支撑体系的动态力学分析及施工全过程进度、资源、成本、质量、安全等的综合信息化管理。



研究了在役结构的安全检测、分析和评估手段,提出针对既有建筑物的运维期信息化管理和数字防灾方法,研制相应的软件系统

对在役结构及其附属设备设施的检测、分析和评估手段进行了研究。在此基础上,面向运维期的建筑、结构和机电设备等组成部分,结合BIM、人工智能、云计算、物联网和GIS等技术,研究运维信息模型的定义和描述,突破跨阶段信息传递技术、模型轻量化技术、跨平台信息共享和系统研发技术、智能运维管理技术等,研发了在役桥梁的检测管理系统和建筑物机电设备智能管理系统等3套软件系统,实现了对既有建筑物在运维期的综合信息化和智能化管理。



研究了建筑全生命期信息管理技术,研制了基于云计算和开放架构的自主知识产权信息平台

面向建筑全生命期的信息集成、管理与应用需求,提出了子信息模型(sub-BIM)的概念,以及跨阶段、递进式、多尺度信息建模方法。在此基础上,基于混合云架构,通过组合自主研发的图形平台和开放平台架构,研制了基于云计算和开放架构的自主知识产权信息平台,满足BIM系统对数据开放、功能开放、人机交互开放的二次开发需求,为推进BIM技术推广和应用提供工具手段。



科研项目

【在研项目】
序号 名称 评论
1 基于GIS/BIM的轻量化平台框架与接口技术 评论
项目来源: 国家重点研发计划子课题
本人角色: 负责人
摘 要: 面向集体统建与村民自建等不同应用需求,研究基于BIM和GIS的乡村住宅多尺度信息模型,突破BIM模型轻量化与高效传输技术,建立轻量化平台数据集成接口规范,研发基于Web的模型可视化与平台框架,实现乡村住宅设计、建造信息的集成与统一对外服务。
2 信息驱动下既有建筑物/群多尺度性能模拟与分析技术研究 评论
项目来源: 国家自然科学基金面上
本人角色: 负责人
摘 要: 以既有建筑运维期信息作为支撑,以BIM和AI等信息技术为驱动,通过对既有建筑性能分析体系的深入研究,面向不同尺度的性能分析需求,提出一个多尺度建筑物运维信息模型,并基于混合云架构实现海量信息的集成高效管理。在此基础上,研究外环境尺度和内环境尺度的信息融合机制,通过技术集成、系统集成和应用集成的方式,研发一个面向既有建筑物/群的多尺度性能模拟与分析系统,以实现多尺度建筑运维期性能分析与预测。
3 基于能耗监测系统的建筑及其机电系统标准化大数据提取技术研究 评论
项目来源: 国家重点研发计划子课题
本人角色: 负责人
摘 要: 针对当前建筑能耗监测系统数据种类多样,内容繁杂的特点,根据子课题1数据提取准则,建立从已有能耗监测系统提取动态标准化大数据的方法,实现云端数据提取软件模块。包括:1)基于子任务1中建筑能耗数据模型,考虑现有分项计量工程的能耗数据传输的不足和缺陷,研究建立面向动态监测的建筑能耗数据模型。2)分析当前能耗监测系统的数据模型,研究采用数据接口和系统集成等方式实现动态能耗监测数据与上述建筑能耗数据模型的集成,以及基于数据挖掘的标准化大数据提取。3)研究基于数据挖掘的建筑及机电标准化大数据提取技术,实现云端数据提取软件模块。
4 移动端三维图形管理模块及模型轻量化 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: 研发“移动端三维图形管理模块及模型轻量化”,实现:1、模型压缩与网络传输优化;2、模型的三角网格简化;3、模型加载及显示优化;4、开发iOS及Android端的三维图形显示模块。
5 基于BIM的动态信息采集与分析技术 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: 建筑的全生命期往往需要牵涉多方互相配合,而当前在建筑行业的实践中,建筑工程的不同参与方互相传递的BIM信息大多是不随时间变化发生的静态信息。在实际的建筑工程项目中的施工和运维阶段往往会产生大量的动态数据,如基于物联网监测设备获取的现场温度、湿度等环境参数,结构应力、应变和位移等结构物参数,以及不断产生的进度变更和维护维修记录等。这些数据不但在数据结构、存储方式、数据结构等方面与静态信息有较大的差别,其中更包含有大量有价值的信息和知识,具有很高的数据挖掘层面的潜力和应用价值。本研究将基于BIM模型及其数据标准,研究基于物联网技术的动态信息大数据的采集技术与方法。在此基础上,针对施工期盾构机作业,运维期建筑能耗监控以及路面损伤识别的具体业务场景,基于物联网监测信息与BIM模型的数据集成技术,以及数据挖掘、大数据分析、图像识别和机器学习等人工智能技术,研究BIM动态信息的大数据标准化提取和智能分析技术,并在上述的实际应用案例中,走通数据获取、分析和处理的完整流程,为施工和运维管理等提供优化决策的支持。
6 广州市市政交通工程BIM技术应用发展战略研究 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: 对广州市市政交通工程 BIM 技术应用发展提供战略研究咨询服务,编制广州市市政交通工程 BIM 技术应用发展战略研究报告。
7 车陂路--新滘东路隧道工程(黄埔大道至新港东路)基于BIM技术的隧道工程精细化设计与施工研究 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: 车陂路-新滘东路隧道工程(黄埔大道至新港东路)南起新港东路、止点至现状黄埔大道交叉口,全长约 2.07 km,道路等级为城市主干路,设计速度 60km/h。隧道工程主线全长 1547m,其中沉管段总长 492m,跨江隧道主线采用双向六车道。利用 BIM 先进技术和历年来项目管理经验,搭建工程项目全设计、施工、运维等全流程的 BIM 应用管理平台,实现隧道管线综合以及沉管管节精细化设计、施工及运维。
8 建筑机电设备知识图谱的构建和应用研究 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: MEP专业(电气、暖通、给排水)设计是建筑设计的重要内容,但由于建筑业数据结构复杂,知识库建设落后,从业人员难以精确获取该领域的所需知识。广联达在建筑信息领域积攒了大量以MEP设计、管理、建设为核心的原始数据。以这些多源异构数据为核心,可构建基于知识图谱的智能搜索引擎。该课题包括三部分内容,第一部分为基于知识图谱的数据结构化处理,需突破MEP领域语料库的收集、自动词性标注、实体识别和关系抽取等技术,由MEP原始数据构造领域知识图谱。第二部分为智能搜索引擎的构建,即基于MEP领域知识图谱,融合自然语言处理及深度学习技术,自动判断用户所需的“知识点”,进而给出用户想要的答案。第三部分是课题总结,研究将本课题构造的知识图谱用于智能问答,MEP构件检索,关联推荐、智慧工地等多项业务的可能。
【结题项目】
序号 名称 评论
1 基于 BIM 的大型公共建筑运维期安全管理技术研究 评论
项目来源: 国家自然科学基金面上
本人角色: 负责人
摘 要: 针对当前大型公共建筑运维期安全管理中存在的海量信息的管理和集成应用方 面等问题,本课题拟结合大型公共建筑的安全管理体系,通过引入 BIM 技术,并结合物联网 技术、云计算技术等国际上新兴前沿技术,基于国际建筑业 IFC 标准,构建一个基于 BIM 和 GIS 的多尺度运维管理模型。在此基础上,以集成创新为主要手段,研究基于云计算技术的 运维信息管理以及基于物联网的安全性能动态监测、评估与预警技术,开发基于 BIM 的大型 公共建筑运维期安全管理平台(BIM-SMP),为大型公共建筑运维期安全信息模型的创建和应 用提供一套完整的理论、方法、技术和平台支持,实现运维期安全的宏观管理和微观管理相 结合、信息管理和信息应用相结合、动态监测和实时评价相结合以及灾后模拟和逃生指引相 结合,可及时发现建筑安全隐患和制定灾后应急方案,进而提高建筑结构及其附属机电设备 的安全性能,减少建筑灾害损失。
成果介绍: 基于BIM的大型公共建筑运维期安全管理技术研究(科普)
2 基于BIM和物联网的再生水厂辅助运维管理 评论
项目来源: 北京市科技计划子课题
本人角色: 负责人
摘 要: 针对槐房水厂建筑物及构筑物繁多、工艺管线复杂等特点,研究设计、施工过程BIM信息的特征,引入建筑业国际标准IFC(Industry Foundation Classes),通过建立机电设备信息模型(MEP-BIM),解决设计、施工阶段BIM机电信息向运维阶段集成交付的问题,实现信息的综合管理和应用;同时,在BIM集成交付模型的基础上,综合应用计算机辅助工程技术(CAE)、虚拟现实技术、人工智能技术、工程数据库、移动网络技术、物联网技术以及计算机软件集成技术,根据北京槐房再生水厂项目的特点和具体需求,应用物联网的核心技术,通过技术集成、系统集成和应用集成等方式,开发“基于BIM的再生水厂辅助运维管理系统”,提供运维阶段的综合信息管理,实现快速获取、管理和处理相关信息,支持运维过程的综合信息、维护维修、运维知识库、机电设备信息管理与应急决策等,从而提高北京槐房再生水厂运维阶段的工作效率和信息化管理水平。
3 面向设计和施工期的建筑物时变结构安全性能的4D模拟和分析 评论
项目来源: 国家自然科学青年基金项目
本人角色: 负责人
摘 要: 当前施工安全分析和管理的手段主要包括工程安全管理和结构安全分析两方面。然而,目前的相关研究主要从其各自的角度来展开,没有联系起来进行综合分析。事实上,导致施工中任何一类安全事故的因素都不是孤立的。为实现集成化的施工期时变结构安全性能的分析和管理,引入信息技术是一条必需和可行的途径。本研究拟引入数据库、人工智能等新兴的计算机信息技术,结合传统结构工程领域中的时变结构分析方法,建立一个面向设计阶段和施工阶段的统一的信息模型,用于存储和管理海量的建筑信息,以及实现多种有限元计算软件中结构分析模型的统一。再应用四维CAD技术来模拟和描述施工全过程,并采用不同的有限元软件进行动态的结构计算,实现施工全过程中结构安全性能的动态模拟和分析,可为设计阶段考虑施工受力变化提供参考,也为施工现场提供新的安全分析手段,从而达到提高设计阶段和施工阶段效率和质量、降低生命周期成本、减少施工过程安全事故发生的目的。
4 基于全生命期绿色住宅产品化数字运营管理技术研究 评论
项目来源: 国家863项目子课题
本人角色: 负责人
摘 要: 通过实现设计、施工阶段与运行维护阶段的信息共享,研究基于全生命期的产品化绿色住宅运维管理技术、绿色性能与安全性能动态监控及评价技术,开发基于全生命期的产品化绿色住宅运维管理系统,为实现绿色住宅运维期的节能减排、防灾减灾和信息化管理提供技术支撑。
5 面向结构设计与施工阶段的统一信息模型的研究与应用 评论
项目来源: 中国博士后科学基金面上资助
本人角色: 负责人
摘 要: 当前施工安全分析和管理的手段主要包括工程安全管理和结构安全分析两方面。然而,目前的相关研究主要从其各自的角度来展开,没有联系起来进行综合分析。事实上,导致施工中任何一类安全事故的因素都不是孤立的。为实现集成化的施工期时变结构安全性能的分析和管理,引入信息技术是一条必需和可行的途径。本研究拟引入数据库、人工智能等新兴的计算机信息技术,结合传统结构工程领域中的时变结构分析方法,建立一个面向设计阶段和施工阶段的统一的信息模型,用于存储和管理海量的建筑信息,以及实现多种有限元计算软件中结构分析模型的统一。再应用四维CAD技术来模拟和描述施工全过程,并采用不同的有限元软件进行动态的结构计算,实现施工全过程中结构安全性能的动态模拟和分析,可为设计阶段考虑施工受力变化提供参考,也为施工现场提供新的安全分析手段,从而达到提高设计阶段和施工阶段效率和质量、降低生命周期成本、减少施工过程安全事故发生的目的。
6 基于BIM和4D技术的施工现场时变结构与可动设施间的动态碰撞检测 评论
项目来源: 中国博士后科学基金特别资助
本人角色: 负责人
摘 要: 本研究通过引进4D技术和BIM,将进度信息与场地实体的空间信息进行严密的整合,组成场地设施的4D时空信息模型,而不再局限于只是一种场地设施随时间变化的三维表现。并基于此4D时空信息模型,结合改进的物理碰撞检测算法,将系统的场地碰撞冲突分析功能扩展至每一个时间点,针对每个时间点对时变结构与可动设施之间进行动态的物理碰撞检测。本研究成果能为加强施工过程中的场地管理,避免由于时变结构与可动场地设施之间发生碰撞而导致安全事故,也为改善施工现场只能依靠管理者进行主观决策的落后局面,提供新的方法和手段,具有理论意义和应用前景。
7 多重灾害作用下大型复杂混合结构工作机理研究 评论
项目来源: 清华大学自主科研
本人角色: 参与
8 重大工程地质灾害快速监测与评估 评论
项目来源: 国家863项目子课题
本人角色: 参与
9 基于BIM的机电设备设施管理系统 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: 本研究通过引入国际标准IFC(Industrial Foundation Classes),基于从设计和施工阶段所建立的面向机电设备的BIM(MEP-BIM),设计机电设备全信息数据库,用于信息的综合存储与管理。在此基础上,开发基于BIM的机电设备智能管理系统(BIM-FIM 2012),其目的一方面是为了实现MEP安装过程和运营阶段的信息共享,以及安装完成后将实体建筑和虚拟的MEP-BIM一起集成交付;另一方面是为了加强运营期MEP的综合信息化管理,为延长设备使用寿命、保障所有设备系统的安全运行提供高效的手段和技术支持。
10 天津富力广东大厦项目投标的BIM技术服务 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: 基于BIM技术和清华大学自主知识产权的“建筑工程4D项目管理系统”,为施工投标方在天津富力广东大厦项目的土建施工投标阶段提供BIM技术服务。主要内容和要求为利用BIM技术和4D系统协助,将甲方建立的BIM模型导入到4D系统中,并在该系统中实现4D施工过程模拟(能够展示相关参数和数据)、资源使用分析、成本费用分析,并形成一套动画。
11 深圳机场T3航站楼玻璃幕墙快速建模 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: 深圳机场T3航站楼的幕墙造型采用了自由曲面上参数化造型的设计,建筑设计方使用空间三维坐标点的方式给出了航站楼外表皮的单层单线模型。在进行施工图深化设计时,需根据该模型以及施工图设计过程中所需的各种指导生产/安装的信息,对原数据进行相应的预处理,从而建立符合施工图要求的多层构造的三维模型,并实现图纸输出。本研究在建筑设计方提供的数据基础上,开发了集预处理、自动建模、后处理等功能于一体的深圳机场T3航站楼幕墙CAD系统(T3-CW-CAD),旨在提高幕墙施工图设计工作的效率。应用结果表明该系统的研发对于指导建筑构件的生产和幕墙系统的施工起到了关键的作用。
12 基于BIM技术的建筑工程安全信息模型及分析软件研究 评论
项目来源: 国家“十一五”科技支撑计划子课题项目
本人角色: 参与
摘 要: 针对建筑工程全生命周期,着眼于建筑施工过程安全分析,基于BIM技术,研究并建立适合我国的建筑工程安全信息模型,研制基于BIM的建筑工程4D施工管理与安全分析系统。包括建立基于BIM技术的建筑安全信息模型、研究施工期建筑结构的安全分析和预测方法、研究建筑施工过程的冲突检测和安全分析方法、建立建筑施工期安全控制管理和决策支持模型、研制基于BIM技术的建筑安全分析与控制系统、将该软件的原型系统试用于实际工程等研究内容。课题于2011年4月15日在北京通过专家组验收和鉴定,评价为“国际领先水平”。
13 建筑设计与施工一体化信息共享技术研究 评论
项目来源: 国家“十一五”科技支撑计划子课题项目
本人角色: 参与
摘 要: 通过深层次的理论研究和高新技术的综合应用,确立BIM的理论、方法和建模技术,引入建筑业国际标准IFC,建立建筑工程设计与施工一体化信息模型和数据交换标准,开发设计与施工信息共享管理平台及相关的支撑软件,从而为实现设计与施工的信息交换、共享和集成化管理,提供研究理论、方法和技术方面的支持,并为开发新一代建筑设计和建筑施工管理系统提供标准、工具和平台,以便进一步解决项目建设各阶段的信息共享,实现建筑全生命期管理奠定基础。
14 《深圳市历史遗留建筑物安全性检测与鉴定规程》 评论
项目来源: 深圳市建设局
本人角色: 参编
摘 要: 由深圳市住房和建设局委托,清华大学深圳研究生院土建工程安全研究中心和中国建筑科学研究院国家建筑工程质量监督检验中心为主编单位,陈肇元院士担任主编,遇平静教授、陈勤博士和胡振中博士参编,会同有关单位共同完成了《深圳市历史遗留建筑物安全性检查评估和检测鉴定规程》。审查会议于2011年11月28日在深圳市迎宾馆召开,认为《规程》针对临时使用建筑的安全评估提出的基于建筑结构状况全面检查的评价方法、对于确认产权建筑物的检测鉴定提出的基于建筑状况分类的抽样检测方法和鉴定要求及安全性鉴定与抗震性鉴定相结合的综合评估方法,具有创新性。;《规程》对深圳市历史遗留建筑的安全性检测鉴定做了系统和详细的规定,对指导和规范该类建筑物的安全性检测鉴定将起到重要作用,具有显著的社会经济效益,其研究内容和方法在国内国家标准及地方标准中属首创,达到了国内领先水平。
15 4D-BIM系统的研发与应用(国家体育场、广州地铁、上海国际金融中心、昆明新机场、中建地产、北京英特宜家、深圳天安高尔夫珑园、青岛海湾大桥、广州西塔、海军总医院9931工程) 评论
项目来源: 横向项目
本人角色: 参与
16 基于BIM的济南黄河公铁两用桥工程施工安全监测与4D动态管理系统 评论
项目来源: 横向项目
本人角色: 参与
摘 要: 在清华大学已有的 BIM(Building Information Modeling)技术研究成果和“基于BIM的工程项目4D施工动态管理系统”软件的基础上,定制开发“基于BIM的济南黄河公铁两用桥工程施工安全监测与4D动态管理系统”,并将该系统应用于济南黄河公铁两用桥工程的实际施工管理过程中。
17 基于BIM的建筑工厂化(设计、加工、仓储)管理系统 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: 本研究通过应用BIM技术,通过开发具有自主知识产权的建筑工厂化(设计、加工、仓储)管理系统,为项目多参与方提供协同工作平台,辅助BIM深化设计、预制构件信息管理、预制构件编码、预制构件加工、现场装配组合。
18 轨道交通BIM管理平台研究与开发 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: 针对广州市轨道交通的建设需求,在清华大学已有的BIM(Building Information Modeling)技术研究成果和“基于BIM的工程项目4D施工动态管理系统”软件的基础上,研发“轨道交通BIM管理平台”(以下简称BIM平台),并为合作方在广州市轨道交通项目提供BIM平台的搭建、接入、使用、培训、定制开发与软件维护等技术服务。
19 基于Web的BIM服务平台研究与开发 评论
项目来源: 自主选题
本人角色: 负责人
摘 要: 本研究为自选课题研究项目,自主研发一个基于WebGL的网页端BIM平台,实现1)BIM模型的浏览与交互;2)面向结构分析的BIM模型转化;3)BIM知识智能搜索引擎。为BIM的进一步跨平台普及推广应用奠定良好的基础。
20 新一代桥梁管理系统软件开发 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: 针对当前的桥梁管理系统普遍存在着管理体系不完整、分析和评估模型落后且不准确、数据库功能不够强大、人机交互体验性不强等问题,基于WebGIS和先进的退化模型、费用模型,开发“新一代桥梁管理系统软件”,实现桥梁在运维过程中的综合信息管理、检查管理、劣化分析、维护管理、报表输出以及决策支持的管理内容。
21 建筑信息模型(BIM)联合研究中心一期项目 评论
项目来源: 横向项目
本人角色: 负责人
摘 要: 在清华大学(土水学院)-广联达软件股份有限公司BIM联合研究中心的支持下,进行以下三个课题的研究:面向BIM的知识引擎的研究与开发(基础研究专项)、基于BIM的时变结构安全性能模拟和分析系统(系统研发专项)、基于BIM的机电设备运维管理系统(系统研发专项)。
22 基于云计算的建筑全生命期BIM集成与应用关键技术研究 评论
项目来源: 国家自然科学基金面上项目
本人角色: 参与
摘 要: 本课题针对当前建筑信息模型(BIM)技术应用于建筑业信息化存在的问题和迫切需求,通过引入国际上新兴的云计算技术,基于国际建筑工业IFC标准,构建一个面向建筑全生命期各阶段和不同应用的BIM结构体系,提出面向建设项目多参与方分阶段递进式的BIM建模方法,研究BIM数据分布存储及管理、BIM数据集成及融合、BIM数据提取与交换以及基于过程的BIM服务及应用等关键技术,开发基于云计算的BIM集成与应用服务平台(BIM Integration and Server Platform,BIMISP)。为建筑全生命期BIM创建和应用提供一套完整的理论、方法、技术和平台支持,实现BIM信息在建设项目规划、设计、施工和运行维护全过程的全局共享、无损传递和充分利用,进而提高工作效率和质量、降低资源消耗,支持在建筑全生命期实施可持续发展战略。
